Blue Origin, the space company founded by Amazon.com’s Jeff Bezos, launched a dramatic flight test over West Texas on Wednesday to verify the performance of an escape system on its reusable suborbital launcher designed to loft space tourists, researchers and commercial astronauts on short rides to the edge of space.
The stubby, single-stage New Shepard rocket took off from Bezos’ ranch north of Van Horn, Texas, at 11:36 a.m. EDT (1536 GMT) Wednesday, about a half-hour later then scheduled after engineers worked out unspecified issues in the final countdown.
About 45 seconds later, at an altitude of around 16,000 feet (nearly 5,000 meters) and a velocity close to the speed of sound, a prototype crew capsule fastened to the top of the rocket fired a solid rocket motor to catapult free of the booster for a crucial in-flight test of the spacecraft’s emergency escape system, which would be triggered to whisk passengers away from an exploding launcher.
No one was inside the capsule Wednesday, but the abort demo is a major milestone toward Blue Origin’s plans to begin flying test pilots on suborbital jaunts above 62 miles (100 kilometers) — the internationally-recognized boundary of space — as soon as next year.
The four-ton capsule spun around and tumbled after the solid-fueled abort motor’s two-second firing, which propelled the vehicle several hundred away from the New Shepard rocket. Guided by reaction control system thrusters, the capsule’s motion stabilized as it deployed three drogue parachutes and three main chutes for a relatively gentle ride back to the ground, touching down at a speed of around 3 mph (5 kilometers per hour) about four minutes after liftoff.
The headless booster continued upward after the capsule was severed, defying predictions that the intense aerodynamic loads and heat from the maneuver would be too much for the rocket’s control system to overcome.
But the New Shepard’s BE-3 main engine, burning a combination of cryogenic liquid hydrogen and liquid oxygen, swiveled to deftly direct its thrust in response to the abort motor firing, keeping the rocket on course.
The engine throttled down as programmed after the capsule jettisoned and burned for about three minutes to reach a point near the von Karman line, the edge of space, before falling back to Earth. Commentators on Blue Origin’s live webcast did not say how high the booster flew.
On the way back down, the rocket, named for Mercury astronaut Alan Shepard, extended a drag brake and wedge fins to slow its velocity, then ignited its BE-3 main engine again less than 30 seconds before landing. Four legs deployed from the base of the booster, and the engine steered the vehicle over Blue Origin’s landing site near New Shepard’s launch pad.
The rocket landing occurred about seven-and-a-half minutes after launch.
The launcher Blue Origin flew Wednesday has now flown five times, dating back to its maiden launch on Nov. 23, 2015, but this mission was its last.
“What an extraordinary test and a tremendous final flight for both craft,” said Ariane Cornell, a manager on Blue Origin’s strategy and business development team, who provided commentary during the company’s webcast of Wednesday’s flight. “As we very optimistically aimed for, both our crew capsule successfully executed its in-flight escape test, and the booster brilliantly continued to space and came home for a fifth landing on our landing pad just two miles north of where it took off from.”
In an email update last month, Bezos wrote that the booster would probably not survive the test flight.
“What of the booster? It’s the first ever rocket booster to fly above the Karman line into space and then land vertically upon the Earth,” Bezos wrote. “And it’s done so multiple times. We’d really like to retire it after this test and put it in a museum. Sadly, that’s not likely.”
The New Shepard’s abort system features a solid rocket motor mounted at the base of the crew capsule to push the spaceship away from the rocket to escape an emergency during launch.
Most previous human-rated space capsules, including the Apollo and Soyuz spacecraft, have their abort motors on top of the rocket, where they would pull the capsule away to get out of the way if the rocket failed. But Blue Origin’s suborbital crew capsule, like commercial orbital-class spaceships being developed by SpaceX and Boeing, has a “pusher” escape system.
The advantage is the escape motor does not have to be jettisoned and thrown away after every mission, as is the case with Soyuz flights. That makes the system more reliable by removing a potential failure mode, and less expensive because the abort motor can be reused until it is needed, then discarded.
With a multimillion-dollar government funding arrangement with NASA, Blue Origin tested the escape system during a pad abort test in October 2012, demonstrating the motor’s ability to drive the capsule away from an explosion on the launch pad.
NASA no longer provides monetary support to Blue Origin’s rocket development program, but the space agency still has “unfunded” agreements to offer engineering expertise.
“This upcoming flight will be our toughest test yet,” Bezos wrote last month. “We’ll intentionally trigger an escape in flight and at the most stressing condition: maximum dynamic pressure through transonic velocities.”
A successful escape test was expected to demonstrate the abort motor’s capability to save the passengers aboard the crew capsule even during the most stressing part of the flight.
During operational crew-carrying flights, a signal from the booster’s computer, the capsule, or mission control could initiate the abort sequence.
While the abort system’s design required the crew capsule to safely land, the New Shepard booster was never designed to survive such a maneuver, according to Blue Origin.
If the rocket ran into trouble after the abort command, its on-board computer would have ordered the BE-3 engine to shut down, and the booster would have plummeted back to the ground and exploded on impact.
“The capsule escape motor will slam the booster with 70,000 pounds of off-axis force delivered by searing hot exhaust,” Bezos wrote. “The aerodynamic shape of the vehicle quickly changes from leading with the capsule to leading with the ring fin, and this all happens at maximum dynamic pressure. Nevertheless, the booster is very robust and our Monte Carlo simulations show there’s some chance we can fly through these disturbances and recover the booster.”
It turns out those computer simulations were right.
Blue Origin officials said they plan to put the New Shepard booster and the crew capsule on public display. New Shepard was the first vehicle to fly to space and return to Earth with a vertical, rocket-assisted landing, logging that achievement on its first flight on Nov. 23, 2015.
The successful recovery of the New Shepard last year came a month before SpaceX, a rival commercial space firm led by Elon Musk, landed a Falcon 9 first stage booster at Cape Canaveral after it sent 11 Orbcomm communications satellites toward orbit.
The Falcon 9 is larger and reached higher speeds than New Shepard, but SpaceX has not yet re-flown a first stage booster. A commercial satellite operator, SES of Luxembourg, agreed in August to put a communications satellite on the first flight of a reused Falcon 9 rocket.
